J&M Power Unit Specifications

J&M Model 200 Power Unit

Engine Type Caterpillar C6.6 Tier III
Horse Power 200 HP (149 kW)
Drive Pressure 0 - 2,500 psi (172 bar)
Drive Flow 100 gpm (379 lpm)
Clamp Pressure 2,500 psi (172 bar)
Clamp Flow 10 gpm (38 lpm)
Engine Speed 2,200 rpm
Weight 9,600 lbs (4,354 kg)
Length 126 in (320 cm)
Width 60 in (152 cm)
Height (Including Muffler) 80 in (203 cm)
Hydraulic Reservoir 280 gal (1,060 L)
Fuel Capacity 130 gal (492 L)

Update Specifications in Grid View Here. Windows Authentification is required.

Click here to view Pilebuck's comprehensive hammer specs

Specifications may vary due to site conditions, specific hammer conditions or product set up. Specifications may change without notice.
Consult the factory for details on any specific product (800) 248-8498.
