APE Vibratory Driver Extractor Specifications

APE Model 64X Vibratory Driver Extractor

SPECIFICATIONS DATA
Eccentric Moment 781 in-lbs (9.00 kgm)
Drive Force 30 tons (269 kN)
Frequency Maximum (VPM) 0 - 1,650 vpm
Max Line Pull 32 tons (285 kN)
Bare Hammer Weight w/o Clamp 4,650 lbs (2,109 kg)
Throat Width 13.75 in (35 cm)
Length 70.00 in (178 cm)
Height w/o Clamp 42.50 in (108 cm)

There is not a power unit recommended with this specific hammer. Excavator mounted units are normally powered by hydraulics on the excavator.
Please consult the factory (800) 248-8498 or visit our Locations page for the phone number of the APE branch closest to you.



Click here to view Pilebuck's comprehensive hammer specs

Specifications may vary due to site conditions, specific hammer conditions or product set up. Specifications may change without notice.
Consult the factory for details on any specific product (800) 248-8498.
